Load index truck tyres

The load index is mentioned on the side of the tyre and is always mentioned together with the speed index. The load index indicates precisely how much weight the tyre is able to cope with (at the correct tyre pressure). Never exceed the load index mentioned on the tyre!
Load index truck tyres

In this example (see image), the first figure (154) indicates the tyre's maximum load (in terms of weight) if it is mounted in single configuration. The second figure (150) also indicates the weight category, but when the tyre is mounted in a double configuration. The figure ‘154’ means the tyre has a maximum load capacity of 3,750 kg - ‘150’ represents 3,350 kg.

Tyre pressure

A tyre's maximum load capacity only applies if the tyre also has an appropriate tyre pressure. Regularly checking tyre pressure has several positive effects:

  • the truck/trailer can be loaded to the maximum limit;
  • the tyre will have a longer life-span;
  • there will be a positive impact on fuel economy; and
  • improved safety is guaranteed.

Insufficient pressure can cost companies (a lot of) money.



LI KG LI KG LI KG LI KG
115 1215 131 1950 147 3075 163 4875
116 1250 132 2000 148 3150 164 5000
117 1285 133 2060 149 3250 165 5150
118 1320 134 2120 150 3350 166 5300
119 1360 135 2180 151 3450 167 5450
120 1400 136 2240 152 3550 168 5600
121 1450 137 2300 153 3650 169 5800
122 1500 138 2360 154 3750 170 6000
123 1550 139 2430 155 3875 171 6150
124 1600 140 2500 156 4000 172 6300
125 1650 141 2575 157 4125 173 6500
126 1700 142 2650 158 4250 174 6700
127 1750 143 2725 159 4375 175 6900
128 1800 144 2800 160 4500 176 7100
129 1850 145 2900 161 4625 177 7300
130 1900 146 3000 162 4750

Identical!

When changing tyres, it is important for the load index of the new tyre to be the same as that of the original tyre. A higher load index isn't a problem, but a lower load index should never be selected. Tyres will only be safe if this basic principle is complied with. If tyres with an identical load index are mounted on a single axle, the required minimum load index applies to each tyre on the axle. If a tyre on one side has a high load index, this will in no way compensate for a tyre on the other side of the same axle, which has an insufficient load index.

Learn more about the speed index
